- PHOTO-2000AH
PHOTO2000AH automatic level Illuminance Meter offers accurate and easy measurement of horizontal illuminance of angled surface.
Because of the good performance such as small size, portability, low power consumption, high accuracy, and wide measuring range, it is especially widely used for field testing.
Parameter
|
Model |
PHOTO-2000AH |
|
Measurement function |
Illuminance、The Illuminance difference、The Illuminance ratio、Integrating time、Integrating Illuminance、The average of Illuminance |
|
Photoelectric sensor |
Silicon photometer head |
|
V(λ)Mis-match |
f1'≤5%（class 1） |
|
Cosine correction |
f2'≤4%（class 1） |
|
Sensitive area |
Φ12mm |
|
Measuring range |
0.01lx～20klx，4 level auto range switch |
|
Accuracy |
±4%（according to JJG245-2005） |
|
Communication interface |
USB（Software available separately） |
|
Holding function |
Holding the readings, easy to read |
|
Standard accessories |
MCU, photometer head, battery, bag |
