150W1000 RF Power Amplifier
150 Watt 80 MHz - 1000 MHz
編 號:150W1000

RATED OUTPUT POWER ...............................................150 watts
INPUT FOR RATED OUTPUT ..........................................1.0 milliwatt maximum
POWER OUTPUT @ 3dB compression
Nominal ................................................................140 watts
Minimum ...............................................................120 watts
POWER OUTPUT @ 1dB compression
Nominal ................................................................120 watts
Minimum ...............................................................100 watts
FLATNESS.....................................................................±2.0 dB maximum; 1.5 dB typical; ±0.8 dB with internal leveling
FREQUENCY RESPONSE ...............................................80-1000 MHz instantaneously
GAIN (at maximum setting) ...........................................52 dB minimum
GAIN ADJUSTMENT (continuous range).........................18 dB minimum (4096 steps remote)
INPUT IMPEDANCE.......................................................50 ohms, VSWR 2.0:1 maximum
OUTPUT IMPEDANCE ...................................................50 ohms nominal
